Designed around real factory constraints, the PM-CQ-15 Automatic High Speed Multi-Needle Quilting Machine keeps workflows simple while raising consistency in Mattress Quilting Machine applications. Feature selection reflects what matters on the floor—reliable motion, quick adjustments, and robust safety, covering multi‑needle quilting workflow. The drive system is sized at approximately 12 kW for stable motion control. The footprint remains manageable at roughly 7000 × 5000 × 2500 mm. It is a dependable choice for teams seeking stable daily output and clear cost control.
| Specification | Value |
|---|---|
| Power | 12 kW |
| Main Shaft Speed | 600–1500 RPM |
| Dimensions (L*W*H) | 7000 × 5000 × 2500 mm |
| Production Speed | 80–360 m/h |
| Quilting Width | 2400 mm |
| Quilting Thickness | ≤ 80 mm |
| Stitch Length | 3–8 mm |
| Needle Type | 24/180, 23/160, 22/140, 21/130 |
| Space Between Needles | 12.7 mm |
| Space Between Needle Rows | 76.2 + 76.2 mm (6″) / 76.2 + 50.8 mm (5″) |
| Max Horizontal Movement | 13 inches (330.2 mm) |
| Voltage | 380V/220V, 60 Hz / 50 Hz |
| Gross Weight | 6500 kg |
| Press Plate Adjustment Range | 2–9 mm |
