PM-CQ-1300 Chain Stitch Multi-Needle Quilting Machine
- Precise Automation: Frequency-controlled main shaft lifts the needle; servo-driven saddle and roller.
- Flexible Arrangement: Needle positions in the 1st and 3rd rows can be freely arranged for various quilting patterns.
- Fast and Stable: Extended swing arms reduce needle swing and fabric holes; special aluminum ensures higher speed and less vibration.
Model: PM-CQ-1300
Brand: Promatic Machinery
Technical Specifications
| Parameter | Value |
|---|---|
| Power | 8.5 kW |
| Main Shaft Speed | 600–1300 RPM |
| Dimensions (L*W*H) | 7300*5000*2500 mm |
| Production Speed | 60–300 m/h |
| Quilting Width | 2450 mm |
| Quilting Thickness | ≤ 80 mm |
| Stitch Length | 3–8 mm |
| Needle Type | 24/180, 23/160, 22/140, 21/130 |
| Space Between Needles | 12.7 mm / 25.4 mm |
| Space Between Needle Rows | 76.2 + 76.2 mm (6″) / 76.2 + 50.8 mm (5″) |
| Max Horizontal Movement | 13 inches (330.2 mm) |
| Voltage | 380V/220V, 60 Hz / 50 Hz |
| Gross Weight | 5500 kg |
