PM-CQ-1400 Chain Stitch Multi-Needle Quilting Machine
- Innovative Versatility: 0.5-inch needle distance allows for more pattern combinations.
- Flexible Precision: 1st and 3rd row needle positions can be freely arranged for diverse quilting patterns.
- Stable Speed: Lengthened swing arms reduce needle swing and fabric holes; special aluminum ensures faster operation and less vibration.
- Accurate Control: Servo-controlled three axes deliver precise quilting; extra buttons simplify hook adjustments.
Model: PM-CQ-1400
Brand: Promatic Machinery
Technical Specifications
| Parameter | Value |
|---|---|
| Power | 11 kW |
| Main Shaft Speed | 600–1400 RPM |
| Dimensions (L*W*H) | 7300*4900*2500 mm |
| Production Speed | 80–330 m/h |
| Quilting Width | 2450 mm |
| Quilting Thickness | ≤ 80 mm |
| Stitch Length | 3–8 mm |
| Needle Type | 24/180, 23/160, 22/140, 21/130 |
| Space Between Needles | 12.7 mm / 25.4 mm |
| Space Between Needle Rows | 76.2 + 76.2 mm (6″) / 76.2 + 50.8 mm (5″) |
| Max Horizontal Movement | 13 inches (330.2 mm) |
| Voltage | 380V/220V, 60 Hz / 50 Hz |
| Gross Weight | 5800 kg |
PM-CQ-1400 Chain Stitch Multi-Needle Quilting Machine
- Innovative Versatility: 0.5-inch needle distance allows for more pattern combinations.
- Flexible Precision: 1st and 3rd row needle positions can be freely arranged for diverse quilting patterns.
- Stable Speed: Lengthened swing arms reduce needle swing and fabric holes; special aluminum ensures faster operation and less vibration.
- Accurate Control: Servo-controlled three axes deliver precise quilting; extra buttons simplify hook adjustments.
Model: PM-CQ-1400
Brand: Promatic Machinery
Detail Pictures & Effect Pictures
