PM-DL-180 Double Wire Pocket Spring Machine
- Spring Type Compatibility: Suitable for both straight and barrel-shaped springs.
- Adjustable Heat Treatment: Easily adjustable to accommodate springs of varying heights for heat treatment.
- Material Efficiency: Features a non-woven fabric connection device that reduces material waste and saves labor.
- Fault Detection: Multiple fault detection systems to effectively reduce losses and improve efficiency.
- Fully CNC Winding: Uses a single-line, dual-wire fully CNC spring winding head, capable of producing zoned springs without manual adjustment.
- Safety Features: Equipped with special protective devices for enhanced safety during operation.
Model: PM-DL-180
Brand: Promatic Machinery
Technical Specifications
| Parameter | Specification |
|---|---|
| Efficiency | 180 pcs/min |
| Non-Woven Supply | 60-100 g/m² |
| Pocket Spring Height | 80-250 mm (can be customized) |
| Wire Dia. | 1.6-2.4 mm |
| Spring Core Dia. | 55-75 mm (can be customized) |
| Non-Woven Width | 340-700 mm |
| Power Supply | 38 kW |
| Air Requirement | 0.02 m³/min 0.8 MPa |
| Weight | 4500 kg |
| Overall Dimension | 5500*1500*2000 mm |
PM-DL-180 Double Wire Pocket Spring Machine
- Spring Type Compatibility: Suitable for both straight and barrel-shaped springs.
- Adjustable Heat Treatment: Easily adjustable to accommodate springs of varying heights for heat treatment.
- Material Efficiency: Features a non-woven fabric connection device that reduces material waste and saves labor.
- Fault Detection: Multiple fault detection systems to effectively reduce losses and improve efficiency.
- Fully CNC Winding: Uses a single-line, dual-wire fully CNC spring winding head, capable of producing zoned springs without manual adjustment.
- Safety Features: Equipped with special protective devices for enhanced safety during operation.
Model: PM-DL-180
Brand: Promatic Machinery
Detail Pictures & Effect Pictures
